240W, input 8-17 VDC, output 20-30 VDC / 10 A, Converter, isolated, connection 13 mm², parallel connection (unlimited), remote switch, IP43.
Remote on-off that eliminates the need for a high current switch in the input wiring. The remote on-off can be operated with a low power switch or by for example the engine run/stop switch (see manual).
Adjustable output voltage: can also be used as a battery charger. For example to charge a 12 Volt starter or accessory battery in an otherwise 24V system.
All models are short circuit proof and can be paralleled to increase output current. An unlimited number of units can be connected in parallel.
High temperature protected. The output current will reduce at high ambient temperature.
IP43 protection, when installed with the screw terminals oriented downwards.
Screw terminals, no special tools needed for installation.
Input fuse (not replaceable), on On 12V and 24V input models only.
Specifications
Manufacturer: Victron
Weight: 1.18 (kg)
Packed Weight: 1.28 (kg)
Length: 186 (mm)
Width: 130 (mm)
Height: 70 (mm)
Dimensions: 186 x 130 x 70 mm (LxWxH)
EAN-Code: 8719076035244
Supplier-Code: ORI122424110
