40 A charge current, 30 A load current, 12/24 VDC, 120 Voc, 40 mA self consumption, LED & LCD, IP20, screw terminal, interface (MeterBus / MODBUS / MSView), data logger. The Prostar MPPT™ solar charge controller with TrakStar Technology™ is an advanced MPPT battery charger for off-grid photovoltaic (PV) systems up to 1100 watts. This controller allows multiple modules in series for 12/24 VDC battery systems. Detailed battery programming options allow for advanced battery support for the latest lithium, nickel cadmium and lead acid battery types.
Specifications
Manufacturer: Morningstar
Weight: 1.4 (kg)
Packed Weight: 1.9 (kg)
Length: 200 (mm)
Width: 170 (mm)
Height: 70 (mm)
Dimensions: 200 x 170 x 70 mm (LxWxH)
EAN-Code: 4250730211399
Supplier-Code: PS-MPPT-40M
