Charge current 18,5 A (Bat1) / 1 A (Bat2), load current (‒), 12 VDC, 60 Voc, self consumption 4 mA, LED, optional pluggable (LCD-Computer S), programmable (DIP-switch), charger for two batteries. The Votronic Duo MPPT controllers are each available in two versions. The marine version is specially modified for boat applications. A microprocessor determines the MPP of the solar module and thus maximizes the power yield. Several charging programs can be set for the living area battery while maintaining the charge of the starter battery. The system can be expanded with the connections for EBL and remote display.
Specifications
Manufacturer: Votronic
Weight: 0.24 (kg)
Packed Weight: 0.24 (kg)
Length: 131 (mm)
Width: 77 (mm)
Height: 40 (mm)
Dimensions: 131 x 77 x 40 mm (LxWxH)
EAN-Code: 4250683618146
Supplier-Code: 11717
